Lever Bias Manual Sewing Unit
Industrial Pleating Machines, Slitters, and Winders in Irvington, NJ
The lever bias Manual sewing unit contains two main components - a 60" Lever Tube Stitching Unit and a 60" Lever Spiral Bias Cutting and Winding Unit with Manual Box swivel.
Features:
- Fabricated steel and cast parts
- Singer Model 281 with edge trimmer for 1/8" pressed open seam. A new Juki #DML5200 can be provided.
- Roll stand unit for unfolded material
- Seam opener with indicator light which alerts operator to thread breakage or thread running out
- Curved heater with rheostat control for temperature change
- Roll reversing mechanism
- Easy clutch motor
- Electrical kit in 220 volt three phase or 110 volt
- Manual box swivel, wood accumulating box
- Steel point type core bar - customer to specify core size*
- Steel overall, drive and idler roller
- One-half horsepower blower motor
- Expanding mandrel 96-152cm with drop extension
- Screw adjustment to change bias angle
- Knife trim assembly
- Adjustable tension clutch
Call (973) 445-9699 or email philip@imperialsewingmachine.com for prices and more information.
